• Suction Capacity: 3 Selectable flow rates of ≥40 L/min, ≥60 L/min, ≥80 L/min
• Vacuum Display: Analog Vacuum Gauge Meter Display
• Maximum Vacuum: Vacuum achievable up to -0.096 mPa (-720 mmHg)
• Vacuum Control: Adjustable vacuum control with flutter-free operation knob.
• Pump Technology: Oil-free piston pump
• Main Unit Body Material: ABS material.
• Motor Capacity (HP): 0.50 standard, Optional: 0.25 / 0.75 / 1.0 as per buyer requirement.
• Noise Level: Quiet operation ≤40 dB(A) compliant with ISO 3741-2010
• Overflow Protection: Automatic overflow protection by floater in the jar.
• Jar Configuration: Standard 3 L × 3 L Polycarbonate collection jars, with lids.
• Jar Material Options: Autoclavable Polycarbonate or Polysulfone jars, with lids
• Reusable Jar Sizes options: available in 2, 2.5, 3, 4 and 5 litres
• Foot Vacuum Control: Optional for convenient operation
• Tubing Options: Silicone or PVC tubing options, with 8 mm or 10 mm internal diameter, Length as per user requirements.
• Ingress protection rating: IP22 compliant with IEC 60529
• RoHS Directive: Complaint with directive 2011/65/EU as Amended (EU) 2015/863 of the European Parliament and of the Council on the restriction of use of certain Hazardous Substances in Electrical and Electronic Equipment’s.
• Power Requirements: AC 220 V ±10%, 50 Hz ±2%

*Technical figures are subject to a tolerance of ±5%. Specifications and design may change without prior notice.
